is this a dtm or stock hedder?
Topic Started: Tue Sep 23, 2008 5:14 pm (1,609 Views)
dennisbots
Member Avatar
Part of things
[ *  * ]
Hey,

I can buy a hedder and the guy tells me it is a dtm hedder.
So can somebody tell me if this is really a dtm hedder because it look to me it is a stock RHD hedder.
I asked him about the dimensions but i did not had a reply yet.

Posted Image

greetings Dennis
Edited by dennisbots, Tue Sep 23, 2008 5:18 pm.
Offline Profile Quote Post Goto Top

Matt
Member Avatar
Administrator - Hawk Eye

Standard 16v manifold.
Offline Profile Quote Post Goto Top

dennisbots
Member Avatar
Part of things
[ *  * ]
are you sure otherwise a dtm hedder go's for verry cheap
Where there even RHD dtm cars?
Offline Profile Quote Post Goto Top

Matt
Member Avatar
Administrator - Hawk Eye

Yes im certain its a standard 16v manifold, same as below:



Posted Image
Offline Profile Quote Post Goto Top

dennisbots
Member Avatar
Part of things
[ *  * ]
ok then i can give you guys the link to haha
here you go
RHD hedder
Offline Profile Quote Post Goto Top

dave_irl
Member Avatar
Defector
[ *  *  *  *  *  *  * ]
It HAS to be possible to modify one of those to fit an 8v right?! I had my head in my engine today and its seriously looks like the only way to pass that damn steering box..
Offline Profile Quote Post Goto Top

dennisbots
Member Avatar
Part of things
[ *  * ]
yea why not
just cut the flange plate of it and weld round connections on there or whatever your exhaust port looks like and make it fit.
Maybe you need to cut a pipe and replace it a bit but nothing big.
And make a new flange plate by hand or with a lasercutter or use one from an other hedder that fit's your head.
That's a hole lot less work then making a new one out of nothing and the disign is probably a lot better as your own disign.

Just make sure you weld the pipe's stress free and the flange plate oterwise it cracks verry fast
Edited by dennisbots, Tue Sep 23, 2008 8:47 pm.
Offline Profile Quote Post Goto Top

Michael
Needs Help
[ *  *  *  *  *  *  * ]
I think it might be a standard 16v one. I don't have vernier at home, but I'm sure the pipes on my Evo 1 are a bigger diameter. :unsure:
Edited by Michael, Tue Sep 23, 2008 8:46 pm.
Offline Profile Quote Post Goto Top

Michael
Needs Help
[ *  *  *  *  *  *  * ]
From another angle, but the ebay one does look different.
Posted Image
Offline Profile Quote Post Goto Top

Matt
Member Avatar
Administrator - Hawk Eye

Thats because your Evo one is a LHD Michael.
Offline Profile Quote Post Goto Top

dennisbots
Member Avatar
Part of things
[ *  * ]
btw all evo's have the same header as a normal 2.5 if i'm correct
should be sweet to get a real class 1 header for my project
maybe i make my own hedder, same as the stock 2.5 but then bigger pipe's if i find the time
Offline Profile Quote Post Goto Top

dave_irl
Member Avatar
Defector
[ *  *  *  *  *  *  * ]
dennisbots
Tue Sep 23, 2008 8:43 pm
yea why not
just cut the flange plate of it and weld round connections on there or whatever your exhaust port looks like and make it fit.
Maybe you need to cut a pipe and replace it a bit but nothing big.
And make a new flange plate by hand or with a lasercutter or use one from an other hedder that fit's your head.
That's a hole lot less work then making a new one out of nothing and the disign is probably a lot better as your own disign.

Just make sure you weld the pipe's stress free and the flange plate oterwise it cracks verry fast
Thats what I was thinking, I mean its just the ends/flange that is really different...

Much easier than making LHD fit RHD.

OK, who has a TIG welder then?? :P

I'd love to do it myself but have never welded.
Offline Profile Quote Post Goto Top

cossie connoisseur
Member Avatar
there can be only one ;-)
[ *  *  *  *  *  *  *  *  * ]
if thats new where was it kept..........in the rain?
Offline Profile Quote Post Goto Top

Michael
Needs Help
[ *  *  *  *  *  *  * ]
cossie connoisseur
Tue Sep 23, 2008 9:40 pm
if thats new where was it kept..........in the rain?
The barrel of Mobil1 that it's sitting on, would cost a € or two. :lol:
Offline Profile Quote Post Goto Top

dennisbots
Member Avatar
Part of things
[ *  * ]
just got a mail from the seller:

the oval port is about 51x30 mm the 4 tubes are 45 mm outside diameter, the two round port are 52 mm when it is a standard hedder then maybe one which did not pass the quality control i found it in a garden of a friend and the ants lived inside, i asked him what it is and he told me it is from Zeuna Augsburg from the mercedes dtm time, they had to work all day long to make many different styles of hedders and often mercedes cancelled their orders because they found better solutions during testing... and this hedder should be one of the cancelled ones... regards andreas
Offline Profile Quote Post Goto Top

JM Motorsport
Member Avatar
More than part of things
[ *  *  * ]
there were no rhd 190 DTM cars
Offline Profile Quote Post Goto Top

mazza
Member Avatar
More than part of things
[ *  *  * ]
MICHAEL
Tue Sep 23, 2008 10:05 pm
cossie connoisseur
Tue Sep 23, 2008 9:40 pm
if thats new where was it kept..........in the rain?
The barrel of Mobil1 that it's sitting on, would cost a € or two. :lol:
Hi everyone!
Howz everyone doing?

its been a while since I added anything over here...lol

I dont think thats a DTM exhaust mate! Zeuna did make different styles of manifolds but i dont think thats a DTM one..

this is a pic of a 2.5-16 / evo i manifold that i have here sitting in the garage and the measurements are bigger...outside diameter of the manifold pipes are 50mm and this manifold does look a little bit tidier with less runs of pipe.

Posted Image
Shot with N91 at 2008-09-25

and this is a pic of a works DTM exhaust

Posted Image
Shot with MX-1200 at 2008-09-25

Hope this helps

mazza

Offline Profile Quote Post Goto Top

cossie connoisseur
Member Avatar
there can be only one ;-)
[ *  *  *  *  *  *  *  *  * ]
the principle problem is that dtm manifolds are LHD where as this one is a RHD

were any genuine MB projects DTM wise done in RHD?
Offline Profile Quote Post Goto Top

mazza
Member Avatar
More than part of things
[ *  *  * ]
cossie connoisseur
Thu Sep 25, 2008 1:16 pm
the principle problem is that dtm manifolds are LHD where as this one is a RHD

were any genuine MB projects DTM wise done in RHD?
hey!

nope!!!! they coudnt even be bothered to makes evos in RHD....LOL

and Mercedes should have made RHD 3.2AMG'S...It would make my life a hell of a lot easier when it comes to insurance....lol

mazza
Offline Profile Quote Post Goto Top

-V-
Member Avatar
The Hamster

Correct - there were never any RHD Evo's made.

Mazza - good to have you back on board! Do they charge you a lot more to insure your LHD AMG then?
Offline Profile Quote Post Goto Top

mazza
Member Avatar
More than part of things
[ *  *  * ]
-V-
Thu Sep 25, 2008 3:47 pm
Correct - there were never any RHD Evo's made.

Mazza - good to have you back on board! Do they charge you a lot more to insure your LHD AMG then?
Hey!

Cheers mate!! Its good to be back, for a little while anyways...he he!

Because the 3.2AMG was never supplied or intended for the UK market, most insurers wont even cover the car because its not on their data base, and the ones that are able to cover tend to go crazy with their quotes.

cheers




Offline Profile Quote Post Goto Top

Matt
Member Avatar
Administrator - Hawk Eye

Good to see you back Mazza. Hope your doing well :)
Offline Profile Quote Post Goto Top

Sev
I am a big Twat
[ *  *  * ]
dennisbots
Tue Sep 23, 2008 9:19 pm
btw all evo's have the same header as a normal 2.5 if i'm correct
should be sweet to get a real class 1 header for my project
maybe i make my own hedder, same as the stock 2.5 but then bigger pipe's if i find the time
according to racing, you can't really improve on the stock 16v/evo headers that much, except by changin the materials they were made of (i.e. re-making a set with the same geometry, but with ceramic coating, for example).

also, 16v headers are different bolt pattern than 8v headers. found this out when someone replied to my thread about supersprint 8v headers. they won't work on 8v.
Offline Profile Quote Post Goto Top

Sev
I am a big Twat
[ *  *  * ]
8v custom headers:

Posted Image
Offline Profile Quote Post Goto Top

dave_irl
Member Avatar
Defector
[ *  *  *  *  *  *  * ]
For LHD though right Sev?

Im really liking the idea of a 2516 one with the ends cut off and an 8v flange/connections on the cylinder head end. I know someone handy with a TIG too - watch this space I suppose?! :)


Offline Profile Quote Post Goto Top

Sev
I am a big Twat
[ *  *  * ]
dave_irl
Thu Oct 2, 2008 11:10 am
For LHD though right Sev?

Im really liking the idea of a 2516 one with the ends cut off and an 8v flange/connections on the cylinder head end. I know someone handy with a TIG too - watch this space I suppose?! :)


yes that's a custom job for lhd 8v's.
Offline Profile Quote Post Goto Top
