How to Replace Soundproof Sheet on Bonnet
Topic Started: Sun May 3, 2009 12:02 pm (14,959 Views)
Avantdi
Member Avatar
Fastest ship in the Galaxy
[ *  * ]
Thought this might be usefull.


First You need to order one of these. Child and fast response fire truck not included.
Posted Image

Part No.
Posted Image

This is the bonnet after removing most of the sound proofing by hand
Posted Image


I used a drill with wire brush on low speed setting to remove the rest
Posted Image


This is what it looked like after wire brush and a quick run round with the hoover to pick up dust
Posted Image


This is the glue I used to attach the soundproofing. Yes it says for rigid materials,plastic & wood. But it is also suitable for foams according to spec sheet.
Posted Image


The job would be a lot easier with two people and the bonnet removed. But there was nobody arround on the day.
So it was a solo job. Offer the sheet up to your bonnet so that you will see it is a snugg fit and needs to be positioned properly from the outset other wise it will be crooked.
I started spraying from the bottom up. Sprayed about 12"s of the lower bonnet portion and attached the lower part of the sheet.
You need to work fastish as the glue sets fairly quickly. But You can lift and reset sheet for a short time. Be sure the lower section is straight before continuing.
Once happy the lower section is straight, I then worked up the bonnet in roughly 12" sections and attached the soudproofing untill finnished.
Posted Image


Result and also keeps that oil burner abit quieter too.
Posted Image

Hope this is of help

Steve B
Offline Profile Quote Post Goto Top

sportline_stu
Member Avatar
More than part of things
[ *  *  * ]
Nice little guide there. Thanks.

Seing how simpe it is has inspired me to do mine.

Stu
Offline Profile Quote Post Goto Top

MadMike
Therapy Needed
[ *  *  *  *  *  * ]
sportline_stu
Sun May 3, 2009 12:37 pm
Nice little guide there. Thanks.

Seing how simpe it is has inspired me to do mine.

Stu
+1
Offline Profile Quote Post Goto Top

rhysmangatmotorsport
Member Avatar
Mangatmotorsport
[ *  *  *  *  *  *  *  *  * ]
nice one, mine is properly ragged now. dealer quoted me £40 for a 16v one, dont they supply the adhesive? where did u buy ur one from?
cheer's robbie..
Offline Profile Quote Post Goto Top

Avantdi
Member Avatar
Fastest ship in the Galaxy
[ *  * ]
rhysmangatmotorsport , bought it a the local dealer here in Cork, Turners cross motors.
It does not come with glue. It was another board member Marv who put me on to the glue which I got from www.safetydirect.ie.
So all in it has cost about €90.

Not too bad
Offline Profile Quote Post Goto Top

RichardCC
Member Avatar
Part of things
[ *  * ]
Inspired me as well to get my finger out and get it ordered and done,

This one needs pinning

Thanks Avantdi
Offline Profile Quote Post Goto Top

alan
Member Avatar
hmmmm interesting
[ *  *  *  *  *  *  * ]
do they actually make much difference to a petrol car as im thinking about one now as it don't seem that hard he says knowing fine well it'll take him twice as long to fit and it'll still end up crooked lol
Offline Profile Quote Post Goto Top

Weyrmaster
Member Avatar
Errrrrrrr!
[ *  * ]
alan
Sun May 3, 2009 2:42 pm
do they actually make much difference to a petrol car as im thinking about one now as it don't seem that hard he says knowing fine well it'll take him twice as long to fit and it'll still end up crooked lol
I managed to find a new one on a scrapper which was hanging right off. Used a similar sorta glue(carpet spray glue), and fitted it in a similar way.
Only prob i have is the glue gets soft with the heat off the engine, and the soundproofing has to be re-done every so often. Serves me right for using cheap glue i spose....lol!
It does make a difference on the 1.8 imo, can't really hear the engine when standing in front of the car, and it seems quieter inside too.
Thats my opinion for what it's worth anyway. :driver:
Offline Profile Quote Post Goto Top

alan
Member Avatar
hmmmm interesting
[ *  *  *  *  *  *  * ]
well maybe get one in the future after all its a merc you aint supposed to hear the engine purring away
Offline Profile Quote Post Goto Top

cossie connoisseur
Member Avatar
there can be only one ;-)
[ *  *  *  *  *  *  *  *  * ]
need to use high temp glue tbh anything else will melt.

what temp as that spray glue useable too? only seen the high temp stuff in metal pots (quite think)
Offline Profile Quote Post Goto Top

Avantdi
Member Avatar
Fastest ship in the Galaxy
[ *  * ]
Temperature good to about 90c. That should be plenty.Have yet to feel a bonnet that hot on a road car unless it was on fire.
Offline Profile Quote Post Goto Top

cossie connoisseur
Member Avatar
there can be only one ;-)
[ *  *  *  *  *  *  *  *  * ]
cool, that should be fine. anyway its not direct heat but radiation that is the problem
Offline Profile Quote Post Goto Top

Avantdi
Member Avatar
Fastest ship in the Galaxy
[ *  * ]
Agreed.

Nice pic off the Mk1 Galictica
Offline Profile Quote Post Goto Top

cossie connoisseur
Member Avatar
there can be only one ;-)
[ *  *  *  *  *  *  *  *  * ]
yeah im a sci fi buff so must be done
Offline Profile Quote Post Goto Top

Avantdi
Member Avatar
Fastest ship in the Galaxy
[ *  * ]
You will be queing early on the 8th of may then.
Offline Profile Quote Post Goto Top

olliecampbell
Part of things
[ *  * ]
Not sure if this is of help, but I found these part numbers:

2016820326:
All 190D 2.2
All 190E from 1987 to F562348
All 190D 2.5 to F562348


2016821326:
All 190E from F562349
All 190D 2.5 to F562348

2016800325:
All 190E 2.6 to F562348

2016800425:
All 190E 2.6 from F562349

From here: https://www.germanstar.net/201bod.htm
Offline Profile Quote Post Goto Top

Avantdi
Member Avatar
Fastest ship in the Galaxy
[ *  * ]
Just a quick update on how the glue is holding out. 3 week in and and it has not shown any problems, alot of traffic driving so plenty of heat generated, The glue is good, so I can recomend it.
Offline Profile Quote Post Goto Top

Toby
Member Avatar
Capt.
[ *  * ]
This is how the 2.6 looks like when installed.

Posted Image
Offline Profile Quote Post Goto Top

moomycossie
Member Avatar
2.3-16v engine now in
[ *  *  *  * ]
very nice well done
Offline Profile Quote Post Goto Top

Toby
Member Avatar
Capt.
[ *  * ]
That's a German 3.2 AMG. Haven't done mine yet was missing the plastic rivets I need for the leading edge and I mean the ones which you can see behind the Grill, they have though today finally after many false starts.

If anyone needs the part number for those extra large plastic rivets it's A 123 990 02 92 I was also told recently they are the same ones which hold the parcel shelf down behind the backrest.

Just added a picture of said troublesome rivet. You need 7 of them.

Posted Image

Edited by Toby, Tue Jun 9, 2009 5:50 pm.
Offline Profile Quote Post Goto Top

Martrider
Member Avatar
Longest build time in history?
Just in case anybody is interested, i have one for sale in the relevent forum section.;)
Offline Profile Quote Post Goto Top

Michael
Needs Help
[ *  *  *  *  *  *  * ]
The insulation on the 2.6 Sportline is completely goosed, so I ordered one from Agnews and just when I was at it, I ordered one for the 2.5 16 (ex Will) as well. I also got the tin of the correct glue from them .

I'll have a go at doing the Sportline tomorrow, then I'll be an expert when I get round to doing the 2.5-16. :lol:


Offline Profile Quote Post Goto Top

rhysmangatmotorsport
Member Avatar
Mangatmotorsport
[ *  *  *  *  *  *  *  *  * ]
thankx for the tip avantdi, I changed mine just before retro, and managed to buy a high temp glue from euro car parts £8.98 all in...
Robbie..
Offline Profile Quote Post Goto Top

gurasis
Newbie
[ * ]
from where did u buy the soundproofing from??????
Offline Profile Quote Post Goto Top

Neil
Newbie
[ *  *  *  *  *  *  *  *  * ]
Mercedes=Benz Dealership!!!!!!

or

Forest Fine Automotive!!!!!!!

:)
Offline Profile Quote Post Goto Top

RyanJG
Member Avatar
Give me fuel give me fire!
[ *  * ]
Hey guys where can you buy them from? Mines in bits all over the enigine! haha.
Offline Profile Quote Post Goto Top

scottx
Tiny penis
[ *  * ]
Nice guide.

Check my pad out. It's from a 2003 GMC Envoy that my wife wrecked and the body shop replaced this anyway. So I took it off before sending it to the body shop. I needed one for my car anyway. :)

Posted Image
Offline Profile Quote Post Goto Top

ChrisFball12
Member Avatar
Yellow Car
[ *  * ]
^that's cool
Offline Profile Quote Post Goto Top

Frankie
Newbie
[ * ]
Hi Steve,

Saw this thread and, as I will be replacing my soundproofing sheet, just wondered how the glue is holding.

Frankie

MB190e from new, 20 years old next month, 331,000 miles and original engine. Quality build in those days
Offline Profile Quote Post Goto Top

merc190uk
Member Avatar
The Godfather

Frankie
Fri Feb 25, 2011 4:32 pm
Hi Steve,

Saw this thread and, as I will be replacing my soundproofing sheet, just wondered how the glue is holding.

Frankie

MB190e from new, 20 years old next month, 331,000 miles and original engine. Quality build in those days
331 ! wow maybe a record on here ! welcome :)
Offline Profile Quote Post Goto Top

Salar
Member Avatar
Salar Turk
[ *  *  * ]
You have done a nice job Avantdi up there, however, how much did the lining cost you?
Offline Profile Quote Post Goto Top

gibpetrolhead
Member Avatar
Racing line
[ *  *  *  *  *  *  *  *  * ]
Salar
Fri Feb 25, 2011 9:56 pm
You have done a nice job Avantdi up there, however, how much did the lining cost you?
Salar that one is £38.77 from mercedes inchcape parts A2018620326.
Offline Profile Quote Post Goto Top

Salar
Member Avatar
Salar Turk
[ *  *  * ]
gibpetrolhead
Fri Feb 25, 2011 10:07 pm
Salar
Fri Feb 25, 2011 9:56 pm
You have done a nice job Avantdi up there, however, how much did the lining cost you?
Salar that one is £38.77 from mercedes inchcape parts A2018620326.
Much obliged, it is about CHF 60, and I think it is logic :)
Offline Profile Quote Post Goto Top

MarkoTheMerc190D
Member Avatar
Diesel Driver
[ *  *  *  * ]
I bought mine in November and still haven't got round to attaching it yet :o
Waiting for a nice warm+sunny spring day B)
Mark
Offline Profile Quote Post Goto Top

jeremy
Member Avatar
Too Far Gone To Help
[ *  *  *  *  *  *  *  *  * ]
Can anyone recommend some glue that is obtainable from Homebase , coz when I went to pack my bonnet pad & glue , I remembered I gave the M-B glue to another member .

The Scotch 90 that is in the above thread is unobtainable near me .


Jeremy
Offline Profile Quote Post Goto Top

kentronix
Member Avatar
I'm only really here for the Kitchens

I used timebond on mine, the tin. It was after reading lots of threads of people recommending it (not specifically merc).
Its been on a few years and hasnt fallen off yet.

You can get it in homebase, b&q and I think halfords. I bought a 500ml tin and I used exactly 1 tin. Homebase seems to only sell the 1L although you may find they have the smaller tin if you buy in store.
Offline Profile Quote Post Goto Top

zoomydek
Part of things
[ *  * ]
nice job, i will be visiting mercedes for some sound proofing next week.
Offline Profile Quote Post Goto Top

df1
Part of things
[ *  * ]
Anyone know the part number of the pad that just covers the battery and fuses ?

I want to keep my 190 standard, don't want the full bonnet cover.

Thanks
Offline Profile Quote Post Goto Top

poormansporsche
Part of things
[ *  * ]
132 quid from mercs now for the 2.6 one !!!!!

Bugger that
Offline Profile Quote Post Goto Top

Neil
Newbie
[ *  *  *  *  *  *  *  *  * ]
See if Forest Fine Automotive are still selling them - I paid about £50 for the 2.6 one, iirc.
Offline Profile Quote Post Goto Top
