Replacement alternator shield pipe 16v; A very cheap replacement OE no longer avaliable
Topic Started: Tue Apr 25, 2017 7:25 pm (533 Views)
ben190cosworth
Member Avatar
NASA, just admit there's aliens :)
[ *  * ]

Hey guys, just creating this thread to help anyone who needs to find a replacement for the no longer available part A0001541386 the alternator heat shielding airflow pipe.

(Sorry if this has been done before lol)

The pipe cost me £12 delivered from a company called Car Builder Solutions, the link to the correct pipe for the 16v (and poss others) can be found here:

http://www.carbuildersolutions.com/uk/classic-ducting-heater-aluminium-paper-covered-40mm-id

Here's the final fitment of the pipe (please excuse my grubby engine bay, its on the list lmao ), it took only a few minutes to fit with the help of fellow members :D

Posted Image

Posted Image

:D


Offline Profile Quote Post Goto Top

mani190cosworth
Part of things
[ *  * ]
did mine 2 month ago with same type of pipe from local motor factors, mine covers the back of the voltage reg and goes to the aluminium shield hole which i think is how it was when new..?
Offline Profile Quote Post Goto Top

ben190cosworth
Member Avatar
NASA, just admit there's aliens :)
[ *  * ]
mani190cosworth
Tue Apr 25, 2017 8:54 pm
did mine 2 month ago with same type of pipe from local motor factors, mine covers the back of the voltage reg and goes to the aluminium shield hole which i think is how it was when new..?

Yea thats about it, theres a smaller diameter hole on the back of the alternator plate and a slot in plastic locator in the ally heat sheild, the pipe slides over both :) ncie and easy
Offline Profile Quote Post Goto Top

JustbeCoz
Part of things
[ *  * ]
That looks good but I would be a little worried about the 120 deg C rating. Have you held a match to the outer covering to see how flammable it is. Cossie manifold puts some serious heat out at WOT.
Offline Profile Quote Post Goto Top

ben190cosworth
Member Avatar
NASA, just admit there's aliens :)
[ *  * ]
JustbeCoz
Wed Apr 26, 2017 2:31 pm
That looks good but I would be a little worried about the 120 deg C rating. Have you held a match to the outer covering to see how flammable it is. Cossie manifold puts some serious heat out at WOT.

I haven't no, but as the air scoop is behind the right head light, I think it will keep it sufficiently cool whilst driving, i hope :)



Offline Profile Quote Post Goto Top

mani190cosworth
Part of things
[ *  * ]
i have not got the alternator plate on the back of my alternator so some of my alternator is exposed, so could do with getting hold of one
Offline Profile Quote Post Goto Top

ben190cosworth
Member Avatar
NASA, just admit there's aliens :)
[ *  * ]
mani190cosworth
Thu Apr 27, 2017 7:56 pm
i have not got the alternator plate on the back of my alternator so some of my alternator is exposed, so could do with getting hold of one

Most deff mate, the back plate protects the wires and rectifier etc, a definite necessary item :) the pipe sends the cold air to the back of the alternator through the scoop behind the headlight on the 16v :)

The part number is A1021540204 but sadly they are no longer avaliable, :(

Edited by ben190cosworth, Thu Apr 27, 2017 9:08 pm.
Offline Profile Quote Post Goto Top

mani190cosworth
Part of things
[ *  * ]
in need of one if anybody has a spare. I presume its the same as a normal 190e, i have cut my pipe so it covers most of the back of the alternator but still need the correct plate cover...
Offline Profile Quote Post Goto Top

fbonaudi
Member Avatar
Newbie
[ * ]
Thanks ben190cosworth for the information. I need to see if this guys ships international.
Offline Profile Quote Post Goto Top

rhysmangatmotorsport
Member Avatar
Mangatmotorsport
[ *  *  *  *  *  *  *  *  * ]
Nice, thanks for sharing Ben
Offline Profile Quote Post Goto Top
